Product description
Compact angled USB-C PD and USB-A charger for use in confined spaces. Intended for charging laptops, smartphones, and tablets. With two ports, two devices can be charged simultaneously.
Support for Power Delivery and multiple fast charging protocols enables automatic adjustment of charging parameters for connected devices. The USB-C port supports Power Delivery up to 65 W, while the USB-A port provides up to 27 W. When used simultaneously, the power is distributed as 45 W + 12 W.
Thanks to GaN technology, high efficiency is achieved in a compact format with low heat generation. The flat design makes the charger suitable for installation in tight spaces, such as behind furniture or in wall sockets with limited space.
Specifications:
- Model: AK-CH-31
- Supply voltage: 100–240 V AC, 50/60 Hz
- Power: 65 W
- Standard: Power Delivery 3.0, Quick Charge 4+, PPS, AFC, FCP, SCP
- USB-C output: 5 V / 3 A, 9 V / 3 A, 12 V / 3 A, 15 V / 3 A, 20 V / 3.25 A
- USB-A output: 5 V / 3 A, 9 V / 2.5 A, 12 V / 2.25 A, 15 V / 1.75 A, 20 V / 1.35 A
- Number of ports: 2, USB-C and USB-A
- Protection: OVP, OCP, OTP, SCP
- Material: ABS
- Color: White
- Operating temperature: 5–50 °C
- Dimensions: 86 x 58 x 46 mm
- Weight: 100 g
- Certifications: CE, FCC, RoHS, REACH
