Relay Functions
Monostable relay – continuous control: When the control signal to the relay coil is removed, the relay contact returns to its rest position (normal state) with the help of a return spring. This is the most common relay type.
Bistable relay – pulse control: The relay contact retains its current position even after the control signal to the coil is removed. No return spring is present.
Switching contact: The relay contact has three terminals – common (COM), normally open (NO), and normally closed (NC). The function corresponds to an on-on switch.
Closing contact: The relay has two terminals and is normally open (NO). The contact closes when the relay coil is energized. The function corresponds to an on-off switch.
Relay Poles: A relay can have one or more poles. The number of poles indicates how many separate circuits can be controlled independently. Example: A 2-pole switching relay has two separate contacts, each with three terminals (COM, NO, NC). This results in a total of 2 × 3 = 6 contact terminals. In addition, there are 2 terminals for the relay coil. In total, the relay has 8 pins/connections.
Shows 1 - 50 of 68 products
product listing
