Product description
Single-pole rocker switch off-on with LED. Ground (chassis) should be connected to the brass-colored terminal. See wiring diagram.
Specifications:
- Breaking capacity: 15 A / 12 VDC
- Voltage (LED): 9–14.4 VDC
- LED current consumption: 16 mA
- LED color: Red
- Function: (off-on), 2 positions – off or on
- Connection: Solder lugs or Faston terminals 4.8 × 0.8 mm
- Panel cutout: 20 × 13 mm
- Panel thickness (min–max): 1 - 3.5 mm
- Mounting depth: 24 mm
