Product description
Door switch for vehicles. Function: NO (normally open), opens the circuit when the door is closed. The switch is grounded to the vehicle chassis using a screw (ø4–4.5 mm). The Faston terminal is grounded (becomes 12 V negative) when the door or engine bonnet is open. The button can be snapped off in one step if it is too long.
Specifications:
- Breaking capacity: 20 A / 12 VDC
- Breaking capacity: 10 A / 24 VDC
- Connection: Faston 6.3 × 0.8 mm
- Mounting hole (body): ø4.6 mm
- Contact surface plate/housing dimensions: 34 × 16 × 2.4 mm
- Mounting depth: 35 mm
- Button length (open position): 9 or 17 mm
- Button length (closed position): 0 or 8 mm
- Button diameter: ø8 mm
