ATtiny461V-10SU SO-20 MCU 8-bit 4kB 256B 256B
Art no: 41011581
Microchip - ATtiny461V-10SU
Do you need assistance?
Call +46 40 298760 (monday - friday 10AM - 4 PM CET) or email us on info@electrokit.se
Product description
Product description
Microcontroller based on the AVR RISC architecture.
Max CPU operating frequency: 10MHz
Flash: 4kB
RAM: 256B
EEPROM: 256B
Features
* 8/16-bit Timer/Counter with Prescaler
* 8/10-bit High Speed Timer/Counter with Separate Prescaler
* 3 High Frequency PWM Outputs with Separate Output Compare Registers
* Programmable Dead Time Generator
* 10-bit ADC
* 11 Single-Ended Channels
* 16 Differential ADC Channel Pairs
* 15 Differential ADC Channel Pairs with Programmable Gain (1x, 8x, 20x, 32x)
* On-chip Analog Comparator
* Programmable Watchdog Timer with Separate On-chip Oscillator
* Universal Serial Interface with Start Condition Detector
Max CPU operating frequency: 10MHz
Flash: 4kB
RAM: 256B
EEPROM: 256B
Features
* 8/16-bit Timer/Counter with Prescaler
* 8/10-bit High Speed Timer/Counter with Separate Prescaler
* 3 High Frequency PWM Outputs with Separate Output Compare Registers
* Programmable Dead Time Generator
* 10-bit ADC
* 11 Single-Ended Channels
* 16 Differential ADC Channel Pairs
* 15 Differential ADC Channel Pairs with Programmable Gain (1x, 8x, 20x, 32x)
* On-chip Analog Comparator
* Programmable Watchdog Timer with Separate On-chip Oscillator
* Universal Serial Interface with Start Condition Detector
Documents
Technical data
Attribute | Value |
---|---|
Adc
|
11
|
Architecture
|
8-bit
|
Case
|
SO-20
|
Clock
|
10 MHz
|
Eeprom
|
0.25
|
Family
|
AVRTiny
|
Flash
|
4
|
Gpio
|
16
|
I2c
|
1
|
Pwm
|
6
|
Ram
|
0.25
|
Spi
|
1
|
Supply-voltage-max
|
5.5 V
|
Supply-voltage-min
|
1.8 V
|
Timers
|
2
|
SKU:
41011581MPN:
ATtiny461V-10SU
