Product description
2.4/5.0 GHz dual-band ISM antenna with w.FL/MHF3 connector. Suitable for WiFi 6E/WiFi 7, also WiFi/WiFi 4/LPWA/Bluetooth/ZigBee/RFID. Mounted using double-sided adhesive tape. Connection via 200 mm cable. Suitable for use in IoT devices, drones and UAVs, home automation, consumer electronics, mobile devices, and industrial, scientific, and medical equipment.
Specifications:
Frequencies (MHz): 2400-2490 / 4900-5900
VSWR: < 2:1
Max antenna gain (dBi): 1.9 / 3.1
Impedance: 50 Ohm
Polarization: linear
Max input power: 2 W
Mounting: Self-adhesive 3M tape
Dimensions: 31.5 x 14.2 x 0.8 mm
Cable: Low-loss ø1.13 mm, 200 mm
Connector: I-PEX3 / MHF3 / w.FL
