Produktbeskrivning
Development board with high power relays, opto-coupled inputs, power supply circuit, crystal oscillator circuit, RS232 port, with ICSP and JTAG ports!
JTAG 5x2 pin connector for in-circuit programming with AVR Debuggers ICSP 5x2 pin connector for in-circuit programming with AVR Programmers Pre-mounted ATMega16-16AI Four mounting holes 3.3 mm (0.13") Voltage regulator +5V, 7805 and filtering capacitors Quartz crystal oscillator circuit - 10MHz Reset IC ZM33064 Status LED
Power plug-in jack RS232 DB9 female connector RS232 interface circuit with Tx, Rx signals 4 optocoupler isolated inputs with screw terminals Input status LEDs 4 relay outputs with 5A/250VAC contacts with screw terminals Output status LEDs Dimensions: 100x80 mm (3.9x3.15")
JTAG 5x2 pin connector for in-circuit programming with AVR Debuggers ICSP 5x2 pin connector for in-circuit programming with AVR Programmers Pre-mounted ATMega16-16AI Four mounting holes 3.3 mm (0.13") Voltage regulator +5V, 7805 and filtering capacitors Quartz crystal oscillator circuit - 10MHz Reset IC ZM33064 Status LED
Power plug-in jack RS232 DB9 female connector RS232 interface circuit with Tx, Rx signals 4 optocoupler isolated inputs with screw terminals Input status LEDs 4 relay outputs with 5A/250VAC contacts with screw terminals Output status LEDs Dimensions: 100x80 mm (3.9x3.15")
