NJM3517 is a stepper motor controller/driver, which requires
minimum of external components and drive currents up to 500mA.
The NJM3517 is suited for applications requiring least-possible RFI.
Operating in a bi-level drive mode can increase motor performance;
high voltage pulse is applied to the motor winding at the beginning
of a step, in order to give a rapid rise of current.
FEATURES
* Internal complete driver and phase logic
* Continuous-output current 2 x 350mA
* Half- and full-step mode generation
* LS-TTL-compatible inputs
* Bi-level drive mode for high step rates
* Voltage-doubling drive possibilities
* Half-step position-indication output
* Minimal RFI
