Product description
65 W USB-C PD GaN fast charger with 2x USB-C PD and 2x USB-A. Compact and powerful USB charger featuring GaN technology, USB-C Power Delivery (PD) and USB-A. The charger provides a combined output power of up to 65 W and can be used to charge and/or power two devices simultaneously, such as a laptop and a mobile phone.
The USB-C ports support Power Delivery with up to 65 W (shared between the ports) and are suitable for laptops, tablets, mobile phones and other USB-C devices. The ports also support PPS (Programmable Power Supply), enabling dynamic adjustment of the output voltage according to the requirements of the connected device.
The USB-A ports provide up to 12 W (shared between the ports) and can be used to charge mobile phones, headphones and other USB devices.
Thanks to GaN technology, the charger combines high efficiency with a compact design. Compared to conventional chargers, this technology enables smaller and lighter designs with efficient power conversion.
The charger has a wide input voltage range of 100–240 VAC, making it suitable for use in many different countries. Built-in protection circuits protect against overcurrent, overcharging and overheating.
Note: The output power is shared between the ports. For example, if USB-C port 2 is loaded with 20 W, USB-C port 1 can deliver a maximum of 45 W.
Specifications:
- Type: USB-C PD GaN fast charger
- Number of outputs: 2 × USB-C, 2 × USB-A
- Total output power (max): 65 W
- USB-C port 1 output power (max): 65 W (shared between the ports)
- USB-C port 2 output power (max): 20 W (shared between the ports)
- USB-A output power (max): 12 W (shared between both ports)
- USB-C: Power Delivery (PD) with PPS
- Input voltage: 100–240 VAC
- Mains plug: Europlug (CEE 7/16)
- Average efficiency: 85.3 %
- No-load power consumption: 0.04 W
- Technology: GaN (gallium nitride)
- Dimensions: 93.4 × 53.4 × 30.2 mm
- Weight: 104 g
USB-C PD port 1 output voltage and maximum load (power shared between the ports):
- 5 V / 3 A (15 W)
- 9 V / 3 A (27 W)
- 12 V / 3 A (36 W)
- 15 V / 3 A (45 W)
- 20 V / 3.25 A (65 W)
- PPS: 5–11 V / 3 A (max 33 W)
USB-C PD port 2 output voltage and maximum load (power shared between the ports):
- 5 V / 2.4 A (12 W)
- 9 V / 2 A (18 W)
- 12 V / 1.67 A (20 W)
USB-A output (power shared between the ports):
- 5 V / 2.4 A (12 W)
