Product description
Compact angled USB-C PD charger for use in confined spaces. Intended for charging laptops, smartphones, and tablets. With two USB-C ports, two devices can be charged simultaneously.
Support for Power Delivery and multiple fast charging protocols enables automatic adjustment of charging parameters for connected devices. When using a single port, up to 65 W can be delivered, while simultaneous charging is distributed as 45 W + 20 W.
Thanks to GaN technology, high efficiency is achieved in a compact format with low heat generation. The flat design makes the charger suitable for installation in tight spaces, such as behind furniture or in wall sockets with limited space.
Specifications:
- Model: AK-CH-32
- Supply voltage: 100–240 V AC, 50/60 Hz
- Power: 65 W
- Standard: Power Delivery 3.0, Quick Charge 4+, PPS, AFC, FCP, SCP
- USB-C output: 5 V / 3 A, 9 V / 3 A, 12 V / 3 A, 15 V / 3 A, 20 V / 3.25 A
- PPS output: 5–20 V / 3 A
- Number of ports: 2 x USB-C
- Protection: OVP, OCP, OTP, SCP
- Material: ABS
- Color: White
- Operating temperature: 5–50 °C
- Dimensions: 86 x 58 x 46 mm
- Weight: 100 g
- Certifications: CE, FCC, RoHS, REACH
