Switched power supply 5V 14A Mean Well LRS-75-5
Art no: 41017959
MeanWell - LRS-75-5
Do you need assistance?
Call +46 40 298760 (monday - friday 10AM - 4 PM CET) or email us on info@electrokit.se
Product description
Product description
Compact switched power supply with one fixed 5VDC output. Screw terminals for all connections. Trimmer for adjusting the output voltage. Protected agains overload, over-voltage and short-circuit.
* Input voltage: 85 - 264VAC / 120 - 373VDC
* Output voltage: 5VDC (4.5 - 5.5V)
* Output current: 14A
* Power rating: 70W
* Efficiency: 86.5%
* Maximum ripple: 100mVpp
* Dimensions: 99 x 97 x 30mm
* Input voltage: 85 - 264VAC / 120 - 373VDC
* Output voltage: 5VDC (4.5 - 5.5V)
* Output current: 14A
* Power rating: 70W
* Efficiency: 86.5%
* Maximum ripple: 100mVpp
* Dimensions: 99 x 97 x 30mm
Technical data
| Attribute | Value |
|---|---|
|
Current-dc
|
14 A
|
|
Outputs
|
1
|
|
Voltage-dc
|
5 V
|
SKU:
41017959MPN:
LRS-75-5EAN / GTIN:
4021087027618
