Product description
Neutrik NL4FXX-W-S is a 4-pole speakON cable connector developed for professional audio applications. It combines robust construction, high rated current and wear resistance. This makes it well suited for audio equipment (PA systems) where reliable connections are required in stage, studio and mobile audio systems.
The connector has a twist lock system that provides a stable and vibration-resistant connection. The conductors are connected via screw terminals. The housing is made of polyamide.
Specifications:
- Number of poles: 4
- Rated current (max): 37 A (Europe, IEC 61984)
- Rated current (max): 35 A (USA, UL1977)
- Rated voltage (max): 250 VAC
- Conductor area: 1.5 - 4.0 mm² (AWG 17-11)
- Outer cable diameter: 6 - 12 mm
- Contact resistance: < 2 mOhm
- Temperature resistance: -33 °C to +80 °C
- Service life (number of connections): approx. 5000
- Protection class / enclosure class: IP20
- Model: NL4FXX-W-S
