Product description
Sense HAT (C) from Waveshare is an expansion module for Raspberry Pi that integrates multiple sensors for motion, orientation, and environmental measurement on a single board. The module connects directly via the standard 40-pin GPIO and communicates over I2C.
The module combines several sensors on one board and enables measurement of acceleration, rotation, magnetic field, air pressure, humidity, temperature, and color.
Specifications:
- Compatibility: Raspberry Pi with 40-pin GPIO
- Interface: I2C
- Supply voltage: 3.3 V via GPIO
- Motion sensor: QMI8658C + AK09918, 6+3-axis IMU (accelerometer, gyroscope, and magnetometer)
- Temperature and humidity sensor: SHTC3
- Barometric sensor: LPS22HB
- Color sensor: TCS34725
- ADC: SGM58031, 4-channel, 16-bit
- Expansion capability: I2C header for additional external sensors
