Product description
The Raspberry Pi High Quality Camera is an affordable and high-quality camera from Raspberry Pi, with excellent low-light performance. The camera sensor is a Sony IMX477R, with a 12.3 Megapixel resolution (4056 x 3040). The sensor is backlit, which provides lower noise and higher light sensitivity. The sensor size of 7.9mm (diagonal) gives a pixel size of 1.55 µm x 1.55 µm.
This version with C/CS mount works with most C or CS Mount lenses. C/CS lenses come in a wider selection than M12, but are both larger and more expensive. With an external lens, different focal lengths and apertures can be had, and focus can be controlled better. The camera "body" is milled from an aluminum block, with a standard 1/4" screw mount compatible with camera tripods. Build a surveillance camera with a wide-angle lens, a microscope with a macro lens, or take artistic photos with a variety of older camera lenses that are available for purchase.
The Raspberry Pi HQ Camera is suitable for both consumer use and industrial applications, such as surveillance cameras.
In addition to taking pictures with software control, the High Quality Camera can also be triggered with an external pulse. This feature enables you to synchronise multiple High Quality Cameras, for simultaneous taking pictures or creating "bullet time" effects.
The camera can take pictures in .jpeg format, RAW, etc. and drivers for V4L2 are available which allows you to control ISO numbers and more.
Supplied with flat cable and three locking rings for M12.
- Sensor resolution: 4056 x 3040 pixels / 12.3 Megapixels
- Sensor: Sony IMX477R
- Video modes: 1080p30, 720p60 and 640 × 480p60/90
- Size: 38 x 38 x 18.6mm excl. lens
- Pixel size: 1.55 µm x 1.55 µm
- IR filter: yes
- Lens mount: C/CS
- Back focus distance: 12.5–22.4mm
Comes with a ribbon cable and C to CS adapter.
Please note that lens is not included and must be purchased separately.
For use with Raspberry Pi 5, the adapter cable (Art. No. 41020808) is required.
