Product description
Prototype board for Raspberry Pi Pico with Qwiic. Expansion board that simplifies building and testing electronics projects with Raspberry Pi Pico or Pico W. The board mounts directly under the Pico. Provides prototyping area and simplifies connection of sensors and peripherals using two Qwiic connectors. With the same form factor as the Pico board, it functions as a base where you can solder components and develop your own circuits. An integrated reset button makes it easy to restart the microcontroller during development, while the built-in Qwiic connectors allow quick connection of I2C-based sensors and modules.
The board is particularly useful during prototyping when combining Raspberry Pi Pico with sensors, displays, or other expansion modules. Thanks to the prototyping area and the direct I2C connection, you can quickly build and test new functions without designing a custom circuit board.
Specifications:
- Compatibility: Raspberry Pi Pico, Raspberry Pi Pico W
- Interface: I2C via 2x Qwiic connectors (JST-SH 4-pin)
- Qwiic connectors connected to: 3.3 V, GND, IO4 (SDA), IO5 (SCL)
- Plated through holes: Yes
- Reset button: Yes
- Dimensions: 52 × 20.4 × 4.7 mm
- Mounting: Mounts under the Pico board
