Product description
Motoron M3T453 is an I2C-controlled motor controller for up to three DC motors. Each motor can be controlled independently, and multiple Motoron controllers can be connected to the same I2C bus for systems with more motors. Supplied without pin headers.
Specifications:
- Product: Motoron M3T453 Triple I2C Motor Controller
- Motors: Up to 3 DC motors
- Interface: I2C
- I2C clock frequency: Up to 400 kHz
- Motor voltage: 4.5 to 44V
- Current rating: 0.8A continuous per motor
- Peak current: 2A per motor for <1s
- Logic voltage: 3.0 to 5.5V
- PWM frequency: 1 to 80 kHz
- Current sensing: Motor channel 1 and 2
- Reverse voltage protection: Down to -40V on motor power supply
- Connections: 2.54 mm pitch
- Pin headers: Not included
- Dimensions: 17.8 x 22.9 mm
