Product description
MC4 male connector for solar panels. Crimp mounting on 4 - 6 mm2 cable. Up to 39 A load.
Specifications:
- Product type: MC4 male connector
- Current max: 39 A
- Voltage max: 1500VDC rms
- Temperature range: -40°C~+85°C.
- Cable: 4-6 mm2
- Mounting: Crimp
- Rating: IP67 (dust and waterproof)
- Pin material: tinned copper
- Housing material: Thermoplastic, UL 94 V-0, Silicone
- Clip material: Stainless steel
- Colour: Black
