Load cell 50Kg

Art no: 41015516
Shop this product, Load cell 50Kg
price 99 SEK
Including 25% VAT
In stock, 59 pcs
Unit : Piece

Do you need assistance?

Call +46 40 298760 (monday - friday 10AM - 4 PM CET) or email us on info@electrokit.se

Product description

OpenClose

Product description

Load Cell for Precise Weight Measurement up to 50 kg. This load sensor, sometimes called a strain gauge is designed as a half Wheatstone bridge (voltage divider) and enables high-accuracy measurement of the force applied to the cell. Note that this load cell has only three connections. This means that at least two load cells must be used to form a full bridge, or two fixed resistors can be used to complete the other half of the bridge.

Wire Color Codes:

  • Red: E+
  • Black: E−
  • White: O+

Specifications:

  • Maximum measurable weight: 50 kg
  • Maximum permissible load: 75 kg
  • Resistance (per element): 1 kΩ
  • Dimensions: 33.8 × 33.8 × 8.7 mm
  • Cable length: 400 mm
  • Operating voltage: 5–10 VDC





Product information

  • SKU:

    41015516
