Product description
Optocoupler with FET output. The output consists of an optically isolated FET transistor with variable resistance. H11F3 can be used as a voltage controlled resistor for AC and DC signals. Suitable for controlling active folters, AGC and sample and hold.
* Forward voltage (LED): 1.3V
* Max input current (LED): 60mA
* Max voltage (FET): ±15V
* Resistance (FET): 470ohm - 300Mohm
* Switch time: 45us
* Isolation voltage: 7500VAC
* Forward voltage (LED): 1.3V
* Max input current (LED): 60mA
* Max voltage (FET): ±15V
* Resistance (FET): 470ohm - 300Mohm
* Switch time: 45us
* Isolation voltage: 7500VAC
