Product description
AG TermoPasty Flux TK83 is a liquid flux supplied in a practical plastic bottle with a brush integrated into the cap. It is highly suitable for manual tinning and for restoring solderability, for example during repair work. It provides excellent wetting of the solder and is well suited for lead-free precision soldering.
The flux can be applied to circuit boards using foam and wave methods, by immersion, or with the integrated brush.
TK83 is a versatile and high-performance flux developed for professional assembly and repair of electronics. It is particularly effective for soldering surface-mounted components (SMD) as well as for manual tinning to restore solderability.
TK83 is a moderately activated flux based on an alcohol solution of rosin, with added organic activators according to EN 29454, ISO 9454 (type 1134) and J-STD-004 (class ROL0).
Residues are non-corrosive after soldering, which means that cleaning is not required (No-Clean type). If desired, residues can be removed with isopropanol (Isopropyl alcohol).
TK83 is intended for professional use in, for example, repair shops, service units, and manufacturing industries.
Note: Always read the safety data sheet before use. Use only in well-ventilated areas. Always reseal the container after use.
Typical applications:
- Assembly of SMD and THT components
- Manual tinning and restoration of solderability
- Machine soldering and tinning of cable ends
Specifications:
- Content: 100 ml
- Application: Brush (integrated in cap)
- Standards: EN 29454, ISO 9454 type 1134, J-STD-004 ROL0
- Density: 0.86 g/cm³ at 20 °C
- Maximum soldering temperature: 280 °C
- Solid content: 24%
- Viscosity: Liquid
- Cleaning: No-Clean type
Warning:
Contains: Isopropanol, Colophonium and Benzoic acid
Hazard:
- H317 - May cause an allergic skin reaction
- H318 - Causes serious eye damage
Precautionary statement:
- P101 - Keep out of reach of children
- P280 - Wear protective gloves and eye protection
- P305+P351+P338 - IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing.
- P310 - Immediately call a doctor
- P333+P313 - If skin irritation or rash occurs: Get medical advice/attention.
