Protoboard for FB01 @ electrokit (1 of 2)

Protoboard for FB01 @ electrokit (2 of 2)

Protoboard for FB01

Art no: 41016084

Electrokit - ProtoPCB - EKB20

Sorry, this product is outdated and no longer active

Do you need assistance?

Call +46 40 298760 (monday - friday 10AM - 4 PM CET) or email us on info@electrokit.se

Product description

Product description

OpenClose

Protoboard made for enclosure FB01. The holes are not connected. Traces can be made using component legs or hook-up wire.

* Dimensions: 59 x 54mm
* Mounting holes (c-c): 43mm (ø3.18mm)
* Component holes: ø1mm
* Grid: 2.54mm (0.1")

Documents

Drawing (pdf, 94.69 KB)

Technical data

Technical data/attributes for this product
Attribute	Value
RoHS	RoHS compatible

SKU:
41016084
MPN:
ProtoPCB - EKB20
HS / TARIC:
8534001900
