Product description
µC compatible power switch with diagnostic feedback for 12 V and 24 V DC grounded loads
* All types of resistive, inductive and capacitve loads
* Replaces electromechanical relays, fuses and discrete circuits
N-channel vertical power FET with charge pump, ground referenced CMOS compatible input and diagnostic feedback, monolithically integrated in Smart SIPMOS
technology. Providing embedded protective functions.
* Overload protection * Current limitation * Short circuit protection * Thermal shutdown * Overvoltage protection (including load dump) * Fast demagnetization of inductive loads * Reverse battery protection
* Undervoltage and overvoltage shutdown with auto-restart and hysteresis * Open drain diagnostic output * Open load detection in ON-state * CMOS compatible input * Loss of ground and loss of Vbbprotection * Electrostatic discharge (ESD) protection
