Product description
Camera module for Arduino and other microcontrollers. Fits into the camera header on Arduino Giga Display Shield and Arduino Giga R1 WIFI. The resolution is 640x480px, the frame rate is 15FPS.
Specifications:
| Image Sensor | OV7675 |
| Active Array Pixels | 640x480 |
| Pixel Size | 2.5µm x 2.5µm |
| S/N Ratio | 38 dB |
| Dynamic Range | 71 dB |
| Interface | 20-pin DVP |
| Shutter Type | Electronic Rolling Shutter |
| Color Filter Array | Quad-Bayer RGB |
| Output Format | RAW/YUV/RGB |
| Resolutions & Frame Rate | 640x480/320x240/160x120@15fps |
| Lens Optical Size | 1/9 Inch |
| EFL | 1.75mm |
| F.NO | 2.8 |
| Field of View Angle | 63.9°(D) |
| Lens Distortion | <1.0% |
| Focus Distance | 0.12M - ∞(AT=0.23M) |
| Power Supply | AVDD: 2.7VA ~ 3.0V DOVDD: 1.7V ~ 3.0V DVDD: 1.5V |
| Operation Temp. | -30° C to 70° C |
| Board Size | 30.5mm x 30.5mm |
