Product description
Development board with a 1.47 inch display based on the Raspberry Pi RP2350. Suitable for embedded systems, prototyping, and visual interfaces.
The board is based on the RP2350 architecture with support for both ARM Cortex-M33 and RISC-V, providing flexibility in the choice of development environment. With support for C/C++, MicroPython, and Arduino IDE, development can be carried out quickly and efficiently, whether for education, IoT, or product development.
The integrated IPS display with a resolution of 172 x 320 pixels provides clear graphics rendering. The board is also equipped with a microSD card slot, RGB LED, and several built-in features such as a temperature sensor and timers.
Thanks to its compact design and USB-C connection, the board is easy to integrate into both stationary and mobile systems.
Specifications:
- Microcontroller: Raspberry Pi RP2350A
- Processor: Dual-core ARM Cortex-M33 and dual-core Hazard3 RISC-V, up to 150 MHz
- Internal RAM: 520 kB
- Flash memory: 16 MB
- Display: 1.47 inch IPS, 172 x 320 pixels, 262K colors
- Interfaces: USB-C (host/device), SPI, I2C, UART
- Storage: microSD card slot
- Other: RGB LED, temperature sensor, built-in timers
- Supply voltage: 5 V via USB or via 5 V / 3.3 V pin
- Pin header: The board can be fitted with pin headers if required (not included)
