ATtiny85-20SU SO-8 8-bit MCU flash 8k

Art nr: 40367085
Handla denna produkt ATtiny85-20SU SO-8 8-bit MCU flash 8k
pris 38.25 SEK
Inklusive 25% moms
Mängdrabatt
AntalPris
1 till9
38.25 SEK
10 till24
34.40 SEK
25 till
28.70 SEK
Lagervara, 24 st
Enhet: styck

10 000 produkter

Snabb leverans

Frakt från 29 kr

Behöver du hjälp? Vi finns här!
Ring 040-298760 (måndag till fredag 10-16), eller mejla på info@electrokit.se

Produktbeskrivning

ÖppnaStäng

Produktbeskrivning

Microcontroller based on the AVR RISC architecture.

Max CPU operating frequency: 20MHz
Flash: 8kB
RAM: 512B
EEPROM: 512B

Features

* 8-bit Timer/Counter with Prescaler and Two PWM Channels
* 8-bit High Speed Timer/Counter with Separate Prescaler
* USI - Universal Serial Interface with Start Condition Detector
* 10-bit ADC
- 4 Single Ended Channels
- 2 Differential ADC Channel Pairs with Programmable Gain (1x, 20x)
- Temperature Measurement
* Programmable Watchdog Timer with Separate On-chip Oscillator
* On-chip Analog Comparator

* debugWIRE On-chip Debug System
* In-System Programmable via SPI Port
* External and Internal Interrupt Sources
* Low Power Idle, ADC Noise Reduction, and Power-down Modes
* Enhanced Power-on Reset Circuit
* Programmable Brown-out Detection Circuit
* Internal Calibrated Oscillator

* Six Programmable I/O Lines
* Speed Grade: 0 - 10 MHz @ 2.7 - 5.5V, 0 - 20 MHz @ 4.5 - 5.5V
* Temperature Range: Industrial (-40° to +85°C)

Egenskaper

Egenskaper/attribut för denna produkt
Attribut Värde
ADC
4
Arkitektur
8-bit
Kapsel
SO-8
Klocka
20 MHz
EEPROM
0.5
Familj
AVRTiny
Flash
8
GPIO
6
I2C
1
PWM
6
RAM
0.5
SPI
1
Matningsspänning (max)
5.5 V
Matningsspänning (min)
2.7 V
Timers
2
UART
1
  • SKU:

    40367085
